World-renowned compressors are used, delivering small vibration, low noise, stable running and excellent weatherability;
Advanced multi-stage gas treatment technology and drainage override system enhance and stabilize the treatment effect and extend the membrane life;
Hollow fiber membrane technology and Jereh’s membrane stabilization technology ensure high separation rate and stable output, fit for the jobs in various conditions;
The advanced horizontal opposed multi-stage compressor and analysis on pulsation and torsional vibration offer steady running, reliable boosting and long continuous operating time;
JNGS full-automatic monitoring system enables real-time monitoring and analyzing of the working data, automatic trouble diagnosis and one-key operation.
| Model | DF 600 | DF 900 | DF 1200 | DF 1500 | DF 1800 | DF 3000 | DF 3600 |
|---|---|---|---|---|---|---|---|
| Discharge Rate | 21,200 SCFH (600 Nm3/h) | 31,800 SCFH (900 Nm3/h) | 42,400 SCFH ( 1,200 Nm3/h) | 52,900 SCFH (1,500 Nm3/h) | 63,600 SCFH (1800 Nm3/h) | 106,000 SCFH (3000 Nm3/h) | 127,200 SCFH (3600 Nm3/h) |
| N2 Pressure | 145~7,250 psi (1～50 Mpa) (optional) | 145~5,076 psi (1～35 Mpa) (optional) | |||||
| N2 Purity | 95% (90～99.9% adjustable） | ||||||
| Drive | Engine / Electric Motor | ||||||
